ABB AF09-30-10-13 3 Pole - 690 V IEC or 600 UL Contactor

ABB AF09-30-10-13 3 Pole - 690 V IEC or 600 UL Contactor

Contact：cassiebirthdayparty@gmail.com

Cables

The use of the NTC for temperature measurement is not suitable for short circuit detection or short term overload, but may be used to protect the module from long term overload conditions or malfunction of the cooling system.

To verify the rated insulation voltage of the IGBT module, all terminals are connected to the high side of a high voltage source.

The base plate is connected to the low side of the high voltage source. This high voltage source with high impedance must be able to supply the required voltage Viso. A test voltage is slowly raised to the specified value determined by equation (19) and maintained at that value for the specified time t.

ABB AF09-30-10-13  Technical drawing:
