ABB TU830V1 Extended Module Termination Unit 2x16 Signal Terminals

ABB TU830V1 Extended Module Termination Unit 2x16 Signal Terminals

Contact：cassiebirthdayparty@gmail.com

Cables

In the above figure, the areas marked with a red circle show excess thermal paste and a rough structure. The images demonstrate clearly that the screen-printing application ensures an optimum distribution and structure of the thermal paste.

The TU830V1 MTU can have up to 16 I/O channels and two process voltage connections. Each channel has two I/O connections and one ZP connection. The MTU is a passive unit used for connection of the field wiring to the I/O modules. It also contains a part of the ModuleBus.
The process voltage can be connected to two individually isolated groups. Each group has a 6.3 A fuse. The maximum rated voltage is 50 V and maximum rated current is 2 A per channel. The MTU distributes the ModuleBus to the I/O module end to the next MTU. It also generates the correct address to the I/O module by shifting the outgoing position signals to the next MTU.

ABB TU830V1  Technical drawing:
