Allen Bradley 1756-OB16IX 3 ControlLogix Discrete Output Module

3 ControlLogix Discrete Output Module

Contact：cassiebirthdayparty@gmail.com

Item NO.:
Allen Bradley 1756-OB16IX
Payment:
T/T
Product Origin:
U.S.A.
Shipping Port:
HongKong
Lead Time:
3 days
Goods Stock:
10
Order(MOQ):
1

Product Detail

Allen Bradley 1756-OB16IX 3 ControlLogix Discrete Output Module

1. All terminals with the same name are connected together on the module. For example,DC(+) can be connected to either terminal marked DC-15.

2. Do not physically connect more than two wires to a single RTB terminal. When you use the second DC-15(+) terminal to daisy chain to other RTBs, always connect the daisy chain as shown.

3. Outputs can be wired in a sink or source configuration as shown above.

4. The jumper bar part number is 97739201. Contact your local Rockwell Automation sales representative to order additional jumper bars, if necessary.

Contact：cassiebirthdayparty@gmail.com

1756-OB16IX Technical drawing:
