Allen Bradley 1794-ACN15 Flex I/O Communication Adapter

Flex I/O Communication Adapter

Contact：cassiebirthdayparty@gmail.com

Item NO.:
Allen Bradley 1794-ACN15
Payment:
T/T
Product Origin:
U.S.A.
Shipping Port:
HongKong
Lead Time:
3 days
Goods Stock:
10
Order(MOQ):
1

Product Detail

Allen Bradley 1794-ACN15 Flex I/O Communication Adapter

6 Rockwell Automation Publication 1794-IN128H-EN-P - October 2022 FLEX I/O ControlNet Adapters Installation Instructions Mounting Dimensions The adapter has the following mounting dimensions:

1. Position the ControlNet adapter module (A) on an IEC standard (35 x 7.5 x 1 mm) top-hat DIN rail, Allen-Bradley® part number 199-DR1; 46277-3; EN50022 (B), at a slight angle.

2. Hook the lip on the rear of the adapter onto the top of the DIN rail, and rotate the adapter module onto the rail.

3. Press the adapter module down onto the DIN rail until flush. Locking tab C snaps the adapter into position and locks it onto the DIN rail.

Contact：cassiebirthdayparty@gmail.com

1794-ACN15 Technical drawing:
