GE IC693MDL645 GE Fanuc Emerson 24-volt DC Positive/Negative Logic Input

GE IC693MDL645 GE Fanuc Emerson 24-volt DC Positive/Negative Logic Input

Situated at the top of the module are two horizontal rows, each row having eight green LEDs.  The LEDs which correspond to the top row input points 1 to 8 are labeled A1 to A8, while those on the second row, which correspond to input points 9 through 16, are labeled B1 to B8.  These LEDs serve to indicate the “on” or “off” status of each input point.

This 24-volt DC Positive/Negative Logic Input module has a rated voltage of 24 volts with a DC input voltage range of 0 to +30 volts DC.  Isolation is 1500 volts between field side and logic side.  The input current at rated voltage is typically 7 mA.  For its input characteristics: the on-state voltage is 11.5 to 30 volts DC while the off-state voltage is 0 to ±5 volts DC.  The on-state current is 3.2 mA minimum and the off-state current is 1.1 mA maximum.  On and off response time is typically 7 ms for each.  Power consumption at 5V is 80 mA (when all inputs are on) from a 5-volt bus on the backplane.  Power consumption at 24V is 125 mA from the isolated 24-volt backplane bus or from user-supplied power.

GE IC693MDL645 Technical drawing:
