Allen Bradley 1746-NIO4V SLC 500 4-Channel Analog I/O Modules 1746-NI04V

Analog Output Modules

Allen Bradley 1746-NIO4V SLC 500 4-Channel Analog I/O Modules 1746-NI04V

Flashing green Device is on-line but has no CIP connections in the established state.

Solid green Device on-line and has CIP connections in the established state.

Flashing red One or more CIP connections in timed-out state. Check for I/O

module failure and controller operation.

Note: This does not apply to POINTGuard I/O connection timeout.

Solid red Duplicate IP address detected.

Verify IP address setting and correct, as needed.

Flashing red/green Module self-test

POINTBus

status

Off Device is not online.

- Device has not completed Dup_MAC_ID test.

- Device not powered - check module status indicator

1746-NIO4V Contact：cassiebirthdayparty@gmail.com

1746-NIO4V Technical drawing:

Allen Bradley 1746-nio4v
