Allen Bradley 1746-OB32 PLC I/O Module for use with SLC 500 Series

32 high-density low-current DC outputs

Allen Bradley 1746-OB32 PLC I/O Module for use with SLC 500 Series

Network

Off No link established with Port 1 or Port 2.

Flashing green Transmit or receive activity present on Port 1 and/or Port 2 @ 100

Mb.

Transmit or receive activity present on Port 1 and/or Port 2.

One port @ 100 Mb and the other port @ 10 Mb.

Solid green Link established with Port 1 and/or Port 2 @ 100 Mb.

Link established with Port 1 and Port 2.

One port @ 100 Mb and the other port @ 10 Mb.

Solid yellow Link established with Port 1 and/or Port 2 @ 10 Mb.

Network

status

Off Device is not on-line

- Device has not completed dup_MAC_id test.

- Device not powered - check module status indicator 1746-OB32 Contact：cassiebirthdayparty@gmail.com

1746-OB32 Technical drawing:

1746-OB32
